Product Information

Specification

Burndy YA34A8N131T38E 4/0 AWG - 500 MCM 3/8" Stud 1 Hole Standard Barrel Aluminum Terminal Lug

Also Known as :

Burndy Connector, Aluminum Terminal Lug, Power Connectors, Burndy Aluminum LUG, Terminal Lug, YA34A8N131T38E.

Description :

Aluminum Terminal, One Hole, 3/8", Stud Size, Narrow Tongue, Internal Chamfer, Tin Plated, Prefilled PENETROX™, End Cap, AL9CU, UL/CSA, 90°C, Up to 35kV, E-Line Series, Pink Color Code, 300 Die Index.

Conductor:

• Copper Str Size Range: 500 kcmil
• Wire Size: 500 kcmil

Certifications and Compliance:

• CSA Approved: Yes
• ETL: No
• UL Recognized: No
• Industry Standard(s): UL 486A-486B
• Standards: Industry Standards Met: UL 486A-486B
• Standards: RoHS Compliance Status: CM
• UL Listed: Yes

Specification:

• Conductor : 4/0 AWG - 500 MCM
• Stud Size: 3/8
• Color Code:  Pink
• Die Index:  300
• EU RoHS Indicator: Yes
• Finish Type: Tin-Plated
• Material:  Aluminum
• Dimension (Stud Size): 3/8 inches
• Physical Attribute: Straight
• Voltage Rating: 35 kV
• Part Number: YA34A8N131T38E
