Product Information

Specification

Shipboard Cable LSTSGU-200 4/0 AWG 3 Conductor MIL-C 24643 Silicone Rubber

Applications:

LSTSGU 3 is a high-temperature unarmored marine cable for essential applications that include power, lighting circuits, and control systems. LSTSGU 3 is suitable for watertight non-flexing applications when completing essential tasks. The cable has a thermoset system and a 1000 V voltage rating.

 Also Known As:

 Type LSTSGU 200 cable, LSTSGU 200, marine wire, anchor marine-grade power wire, anchor marine grade boat battery cable, marine-grade wire, boat steering cable, shore power cable, boat cables, marine power cord, marine shore power cord, marine-grade cable, marine steering cable, marine cord, marine electrical cable, boat control cables, marine power cable, marine control cables, marine shipboard cable, marine cable types, tinned copper wire marine, cable boat, marine shore power cable, anchor marine cable, tinned marine cable Us, marine wire cable, boat cable, marine battery cable, boat throttle cable, boat battery cables, marine push-pull cable, marine-grade battery cable, outboard battery cable, ancor battery cable

Standards:

• • MIL-C-24643/24
• • ANSI/NCSL Z540-1
• • MIL-I-45208A
• • MIL-STD-790
• • NHB 5300.4 (1C)
• • ISO 9001:2000

Construction:

Conductor:

Nickel-coated copper three conductors with a class B or C stranding per ASTM B8. Nickel coating helps to enhance the corrosion-resistance properties of a cable.

Insulation:

An extruded silicone rubber insulation with a glass braid covering. The insulation is flexible, hydrophobic, and has high tensile strength. It is resistant to ozone, UV, most industrial chemicals, and oils. The insulation is covered with a glass braid.

Jacket:

A cross-linked polyolefin jacket with a surface marking. It has excellent fire and UV resistance.

Shield:

A braided aluminum armor offers extra protection to the cable.

Specification:

• • Armor: No
• • Conductor Count: 3 Conductors
• • Conductor Size: 4/0 Awg (American Wire Gauge)
• • Conductor Stranding: Class B
• • IEEE 45: No
• • Insulation Material: Sr-silicon Rubber
• • Jacket Material: Po-polyolefin
• • Mil Spec; Mil-c 24643
• • Navy Size: 3
• • Screen/shield : No
• • Ul: No
• • Watertight: Yes
• • Unspsc Code 26121603
• • Mil-spec # M24643/16-10-UN

*Data provided on this page is subject to change based on different manufacturers' variances

** Images are for display purposes only refer to Product Technical Details for accurate information on the product.

In the case the material only comes in a predetermined color or doesn’t come with any color
