Igus Single SpeedTec DIN Connector Allen Bradley 2090-CSBM1E1 Power Cable

Also Known as:

Power Connector, Igus Single SpeedTec, IGUS, Servo Cable, IGUS Single SpeedTec Connector, Allen Bradley Connector

Construction:

• Conductor: Fine-wire stranded conductor in especially bending-resistant version consisting of bare copper wires (according to DIN EN 60228)

• Conductor Insulation: Mechanically high-quality, especially low-capacitance TPE mixture

• Conductor Construction: Power cores with control pair elements stranded with elements for high tensile stresses

• Conductor Identification: 4G6.0 3 black cores with white printing: 1. core: U/L1/L+ 2. core: VL/L2 3. core: W/L3/D/L- followed by one green-yellow core
(2x1.0)C 2 black cores with white numerals: 5 - 6
(2xAWG22)C therefrom one core in white and one in blue

• Element shield: Bending-resistant braiding made of tinned copper wires.

• Jacket Color: Pastel orange (similar to RAL 2003)

• Outer jacket: Low adhesion mixture on the basis of PUR, adapted to suit the requirements in e-chains® (According to DIN EN 50363-10-2)

Properties and Approvals:

• UV resistance: Medium
• Oil Resistance: Oil-resistant according to DIN EN 50363-10-2
• Offshore: MUD-resistant following NEK 606 - status 2009
• Flame retardant: According to IEC 60332-1-2, CEI 20-35, VW-1, FT-1
• Silicone-free: Free from silicon which can affect paint adhesion (according to PV 3.10.7 – status 1992).
• Halogen-free: Following EN 60754
• UL/CSA AWM: See data sheet for details
• NFPA 79: Following NFPA 79-2012 chapter 12.9
• EAC: Certified according to No. TC RU C-DE.ME77.B.01255
• CTP: Certified to no. C-DE.PB49.B.00420
• Lead free: Following 2011/65/EU (RoHS-II)
• CEI: Following CEI 20-35
• Clean room: According to ISO Class 1. Outer jacket material complies with CF27.07.05.02.01.D, tested by IPA according to standard 14644-1
• DESINA: According to VDW, DESINA standardization
• CE Guideline: Following 2014/35/EU
