Product Information

Specification

Application:

This conduit is intended for installation in accordance with Article 350 of the NEC (ANSI/NFPA-70):

• Permitted for use in exposed or concealed locations.
• Installations under raised floors in Data Processing Areas. Article 645.5(E)
• Listed and marked for direct burial and in poured concrete.
• Meets same specifications as Type LA.

This conduit is intended for use according to the Canadian Electrical Code (CEC CSA 22.1-18) as described in clause 12-1300 for dry, damp or wet locations.

• Conforms to CSA C22.2 No. 56-17 Annex A “Heavy Duty”


Hazardous Locations areas where flexibility is necessary:

• Class I Div 2: CSA 22.1 J18-152 (1) (i)
• Class II Div 1: CSA 22.1 J18-204 (4) (b)
• Class II Div 2: CSA 22.1 J18-254 (1) (h)
• Class III Div 1: CSA 22.1 J18-304 (1) (f)
• Class III Div 2: CSA 22.1 J18-354 (h)
• Zone 2: CSA 22.1 18-152 (1) (h)
• Zone 20: CSA 22.1 18-192 (3) (a)
• Zone 21: CSA 22.1 18-202 (4) (a)
• Zone 22: CSA 22.1 18-252 (1) (h)

Markets:

• Data Centers

Also Know As:

Electri Flexible Conduits, Flexible Conduits, Galvanized Steel, Liquidtight Jacket, Type CBLA Conduits, Jacketed Metallic, Flexible PVC, Flexible Steel Conduit

*Data provided on this page is subject to change based on different manufacturers' variances

** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
