Alpha Wire 5909/15C 22 AWG 15 Pair Foil Shield PVC Insulation 300V Communication and Control Cable

Alpha Wire 5909/15C 22 AWG 15 Pair Foil Shield PVC Insulation 300V Communication and Control Cable
Roll over image to Zoom

Alpha Wire 5909/15C 22 AWG 15 Pair Foil Shield PVC Insulation 300V Communication and Control Cable

SKU: NNC20501X
alpha-wire-multi-pair-foil-shield-pvc-insulation-300v-communication-and-control-cable

Availability: In stock

Min Length: 1 FT
Max Length: 10000 FT
Price:
Regular price
$9.35
Sale price
$6.80 /FT 27% off
Shipping Cost Calculated at Checkout. Standard Lead Time is 1 to 6 Business Days.
Free Shipping: On orders above $1000
Quantity must be 1 or more

Enter the required footage in the quantity box - Cut to one length

Where are we? 4 Continents 8 Countries

map
garrie

Got any Questions?

Speak with a real person who will go out of their way to help you!

Call Us: 1-516-482-6313Text Us: 1-516-703-3460

Chat

Live Chat: Bottom Right Corner!

Email Us

info@nassaunationalcable.com

Product Information

Specification

Communication and Control 300V Overall Foil Shield, Multipair, PVC, PVC

UL AWM 2464 VW-1 UL CM CSA CMG FT4

Operating Temperature:

• -20°C to +80°C (AWM)
• -20°C to +75°C (CM)
• -20°C to +60°C (CMG)

Conductor Color Coding:

• Chart K (page 529)

Materials:

• Solid tinned copper conductors
• PVC insulation
• Aluminum/polyester foil shield, 25% overlap min. Foil facing inward Stranded tinned copper drain wire equal in size to conductor
• Slate PVC jacket

Availability:

100 ft (30.5 m)
500 ft (152 m)
1000 ft (305 m)

Specification:

Conductor Count 15 PAIR
Conductor Material Tinned Copper
Conductor Size 22 AWG
Conductor Type STRANDED
Insulation Material PVC
Jacket Material PVC
Product Type Communication and Control Cable
RoHS Compliant YES
Screen/Shield Type YES
Screen/Shield FOIL
Standards CA Prop 65, CSA CMG, CSA FT4, UL AWM 2464, UL CM, UL VW-1
Voltage Range 300V

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
