TYPE W MAGNET CRANE CABLE MARINE CABLE 2000V
Select a Gauge
Where are we? 4 Continents 8 Countries
Got any Questions?
Speak with a real person who will go out of their way to help you!
Call Us: 1-516-482-6313Text Us: 1-516-703-3460
Chat
Live Chat: Bottom Right Corner!
Email Us
info@nassaunationalcable.com
Quick Support
| Product Name | Length | Price (Per FT.) | Action | |
|---|---|---|---|---|
 |
Product Name |
Length
/FT
|
Price (Per FT.)
Call 516-482-6313 for pricing
|
Action
|
|
Product Name |
Length
/FT
|
Price (Per FT.)
$4.22 |
Action
|
|
Product Name |
Length
/FT
|
Price (Per FT.)
Call 516-482-6313 for pricing
|
Action
|
|
Product Name |
Length
/FT
|
Price (Per FT.)
$5.27 |
Action
|
|
Product Name |
Length
/FT
|
Price (Per FT.)
Call 516-482-6313 for pricing
|
Action
|
|
Product Name |
Length
/FT
|
Price (Per FT.)
$8.25 |
Action
|
|
Product Name |
Length
/FT
|
Price (Per FT.)
Call 516-482-6313 for pricing
|
Action
|
|
Product Name |
Length
/FT
|
Price (Per FT.)
$12.45 |
Action
|
|
Product Name |
Length
/FT
|
Price (Per FT.)
Call 516-482-6313 for pricing
|
Action
|
|
Product Name |
Length
/FT
|
Price (Per FT.)
$12.71 |
Action
|
|
Product Name |
Length
/FT
|
Price (Per FT.)
Call 516-482-6313 for pricing
|
Action
|
|
Product Name |
Length
/FT
|
Price (Per FT.)
Call 516-482-6313 for pricing
|
Action
|
|
Product Name |
Length
/FT
|
Price (Per FT.)
Call 516-482-6313 for pricing
|
Action
|
|
Product Name |
Length
/FT
|
Price (Per FT.)
Call 516-482-6313 for pricing
|
Action
|
|
Product Name |
Length
/FT
|
Price (Per FT.)
Call 516-482-6313 for pricing
|
Action
|
Product Information
Specification
Type W Magnet Crane Cable Marine Cable 2000v
Applications:
Type W Magnet Crane Portable Power Cable is an electrical cable used in heavy-duty applications, magnet cranes, drills, scrap yards, foundries,and pumps where flexibility and durability is a must. The electrical cable is resistant to abrasion, tears, cutovers, cut-throughs, and other kinds of a severe mechanical impact. In dry conditions, Type W Magnet Crane Cable is suitable for temperatures between 105° C and -55° C. Type W Magnet Crane Wire has a 2000V rating.
Also Known As:
Type W Magnet Crane Portable Power Cable, Type W Magnet Crane Wire, Type W Magnet Crane Marine Cable, Type TC Magnet Crane Cable, Type W Magnet Crane Direct Burial Wire, Type W Magnet Crane Flexible Cable.
Standards:
- ASTM B-3, ASTM B-172, and UL-62 (Conductor)
- UL Listed Type W
- NEMA WC-58 (Suitable for mining applications)
- ICEA S-95-658/ NEMA WC-70
- MSHA P-184
- FT-4 Flame Test
Construction:
Conductor:
Extra-flexible rope stranding (Class K), soft-drawn uncoated copper; per ASTM B-3, ASTM B-172, and UL-62. Conductors are cabled with non-wicking, nonhygroscopic fillers with an overall binder of rubberized fabric tape
Insulation:
Color-coded Thermoset (EPDM) insulation per UL-62 and ICEA S-68-516
Jacket:
CPE rubber jacket
MARINE WIRE TYPE W MAGNET CRANE CABLE 105° C TO -55° C
2000 VOLT
APPLICATIONS:
The intention of the Magnet Crane wire is built to be able to resist the abusive situations mainly in magnet crane areas of action. These wires resist cuts over, puncture, tearing, abrasion and impact better than standard Type W, due to the rough design and material choice. Magnet Crane Cables are perfect for use in scrap yards, foundries, and other installations where there is a severe risk of metal cut through.
FEATURES AND BENEFITS:
- Extra-flexible rope stranding (Class K), soft-drawn uncoated copper; per ASTM B-3, ASTM B-172, and UL-62.
- Great flexibility, long flexibility lifespan, reduced copper fatigue and conductor rupture.
- Paper separator / Easy stripping
- Color coded Themoset (EPDM) insulation per UL-62 and ICEA S-68-516
- Excellent physical and electrical properties, easy conductor identification, will not melt or deform during emergency overload or short circuit conditions
- Conductors are cabled with non-wicking, nonhygroscopic fillers with an overall binder of rubberized fabric tape
- Strength increased mechanical and impact resistance, and exceptional performance in severe flexing applications
RATINGS:
Magnet Crane Cables are rated for constant operation at 105° C to -55° C in all dry situations. Cables are also UL listed (E130231) Type W 2000 volts 90° C with in wet or dry, sunlight resistant, -40° C and are certified CSA (LL36970) Type W, 2000 volt, -55° C FT1.
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
