Belden 83806 12 AWG 6C Stranded Tinned Copper Braid Beldfoil Shield FPLP FEP Electronic Cable
Allowable Ampacity for Belden 83806 12 AWG 6C Stranded Tinned Copper Braid Beldfoil Shield FPLP FEP Electronic Cable: 100 Amps
Also Known as:
Electronic Cable, Multi Conductor Cable, Audio Cable, Multi Pair Cable, Belden Cable
Description:
Multi-conductor cables generally carry audio, control, and instrumentation signals via a wide array of options. Multi-conductor cables are very similar to multi-pair cables, differentiated by the pair qualification.
Specifications:
Gauge Size: 12
Stranding: 7x20
No. of Conductors: 6
Armor Type: None
Conductor Configuration: Conductors
Conductor Metal: Tinned Copper
Conductor Shielding Type: Unshielded
Conductor Type: Stranded
Insulation Material: FEP
Jacket Material: FEP
Supplier Series: 83806
Overall Shielding Type: Al Foil/Poly Tape & Tc Braid
Specification(s): NEC CMP/FPLP
Temperature: 200C
Voltage: 300V
IEWC Part: 32041268
Manufacturer: Belden
