Belden 1369P 18 AWG Solid Bare Copper RG6 Duofoil TC Braid CMP Serial Digital Coax Cable
Allowable Ampacity for Belden 1369P 18 AWG Solid Bare Copper RG6 Duofoil TC Braid CMP Serial Digital Coax Cable: 100 Amps
Also Known as:
SDI Cable, Coaxial Cable, RG6/U Cable, Technical Data Cable, Belden Cable, Video Cable
Description:
RG-6/U is a 75 Ohm common coaxial cable that usually has an 18AWG conductor, often used for broadband and cable TV applications. RG-6 is a bit larger than the RG-59.
Specifications:
Gauge Size: 18
Stranding: 1
No. of Conductors: 1
Armor Type: None
Coax Construction: Coaxial
Conductor Diameter: 0.040"
Conductor Metal: Bare Copper
Conductor Shielding Type: Not Specified
Conductor Type: Solid
Impedence: 75 OHMS
Insulation Material: FOAM FEP
Jacket Material: LS-PVC
Overall Shielding Type: Al Foil/Polyester Tape/Al Foil
Supplier Series: 1369P
Temperature: Not Specified
IEWC Part: 32039097
Manufacturer: Belden
