20 AWG 1C 7 Strand Nickel Plated Copper Unshielded UL 3257 Silicone 250C 25KV Hook-Up Lead Wire

Name: 20 AWG 1C 7 Strand Nickel Plated Copper Unshielded UL 3257 Silicone 250C 25KV Hook-Up Lead Wire
Brand: IEWC Cable
SKU: NNC3257250CRD
Price: 670.81 USD
Availability: InStock
Rating: 4.92 (8248 reviews)

Roll over image to Zoom

Write a Review

Ask a Question Download PDF Buyer Guide

SKU: NNC3257250CRD

Select a Gauge

20 AWG 1C 7 Strand Nickel Plated Copper Unshielded UL 3257 Silicone 250C 25KV Hook-Up Lead Wire

Availability: In stock

Price:

Precio habitual: $670.81 /Qty
Precio de oferta: $670.81 /Qty

Los gastos de envío se calculan en la pantalla de pagos.

Free Shipping: On orders above $1000

Size

Color

Qty:

Enter the required footage in the quantity box - Cut to one length

Where are we? 4 Continents 9 Countries

Got any Questions?

Speak with a real person who will go out of their way to help you!

Call Us: 1-516-482-6313Text Us: 1-516-703-3460

Chat

Live Chat: Bottom Right Corner!

Email Us

info@nassaunationalcable.com

Quick Support

Product Information

Specification

20 AWG 1C 7 Strand Nickel Plated Copper Unshielded UL 3257 Silicone 250C 25KV Hook-Up Lead Wire

Allowable Ampacity for 20 AWG 1C 7 Strand Nickel Plated Copper Unshielded UL 3257 Silicone 250C 25KV Hook-Up Lead Wire: 100 Amps

Also Known as:

High Temperature Cable, High Voltage Cable, UL 3257 Cable, Hook-up Cable, Lead Cable, Silicone Cable

Description:

UL 3257 silicone insulated hook-up wire that is used for internal wiring where it is not exposed to flexing. Rated for 250C, 10,000VAC, and 25,000VDC.

Specifications:

Gauge Size: 20
Stranding: 7
No. of Conductors: 1
Armor Type: None
Conductor Metal: Nickel Plated Copper
Conductor Shielding Type: Unshielded
Conductor Type: Stranded
Insulation Material: Silicone
Jacket Material: None
Overall Shielding Type: Unshielded
Specification(s): UL 3257
Temperature: 250C
Voltage: 25kV
IEWC Part: 3257/20N07-1
Manufacturer: Radix Wire
Manufacturer Part: EDA20P007-T01
