Product Information

Specification

MULTI-CONDUCTOR NON-PLENUM EACH PAIR SHIELDED(EPS)

Applications:

The fire alarm cable is an electrical wire that is used in signaling, remote control, communication systems, nurse call, and power-limited circuits. The operating temperature range of this electrical cable is from -20°C to 60°C, and the power limit is 300V.

Also Known As:

Fire alarm wire, fire alarm cable, smoke detector wiring, smoke alarm wiring, wiring fire alarm system.

Standards:

• UL Type CMR/CL3R – CMX Outdoor / cUL Type CMG/FT4
• NEC Article 725 & 800
• California State Fire Marshall

Construction

Conductors:

This fire alarm cable conductor is made of bare copper. Copper is used for this application because of its amazing electrical properties and flexibility.

Insulation:

The fire alarm wire has PVC insulation. It can withstand a wide range of temperatures, is resistant to chemicals and UV light deformations, water-tight, and easy to cut.

Jacket:

The smoke alarm wiring has a PVC jacket with a rip cord. It is resistant to extreme temperatures, chemicals and UV light deformations. It is also water-tight and easy to cut.

Shield:

This cable has a mylar-backed aluminum tape shield with 100% coverage.

*Data provided on this page is subject to change based on different manufacturers' variances

** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
