1" Trade Electri Flexible Conduits Shield Interlocked Bronze Type EMS Liquidtight Jacket PVC

• US Trade Size: 1"
• ISO: 32 mm
• CSA: 27 mm
• Type: EMS-13
• Internal Diameter: Min: 1.041 Inches & Max: 1.066 Inches
• Outer Diameter: Min: 1.290 Inches & Max: 1.315 Inches
• Inside Bend Radius: Static: 4.0 Inches

• Weight: 89.25 Lbs
• Reel 100ft: Part Black: 78832
• Reel 400ft: Part Black: 78834


1" Trade Electri Flexible Conduits Shield Interlocked Bronze Type EMS Liquidtight Jacket PVC

Allowable Ampacity for 1" Trade Electri Flexible Conduits Shield Interlocked Bronze Type EMS Liquidtight Jacket PVC: 100 Amps

Application:

• Accepts Standard Metallic Liquidtight Fittings
• Designed for wiring applications requiring shielding effectiveness from Electromagnetic and Radio Frequency Interference (EMI/RFI)

Shield-Flex, EMS and HFEMS are trademarks of Electri-Flex Company, registered in the U.S. Patent and Trademark Office.

Also Know As:

Electri Flexible Conduits, Liquidtight Jacket, Type EMS , Zero Halogen, Low Smoke, Flexible Conduits, Flexible PVC

Markets:

Aerospace, Cell Towers, Defense, Healthcare, Renewable Energy, Ship Building, Telecommunications

Type EMS:

Type EMS has an inner core that is made from a fully interlocked bronze strip and does not contain a braided shield.

For a low-smoke, low flame spread, zero-halogen version, ask for HFEMS.

Construction:

Inner Core:

• Bronze
• 3/8” – 4” Fully Interlocked Profile

Liquidtight Jacket:

• Flexible PVC
• Resistant to Oils and Mild Acids
• Flame Retardant
• Sunlight Resistant (UV)
